*Materials
We use a wide range of glass types for the production of our capillaries.
We obtain them from well-known, large manufacturers as well as from small manufacturers of special glasses whose careful manufacturing processes guarantee a high product quality. For some applications we use glasses from specialized suppliers who can manufacture glasses is small quantities and on a laboratory scale.

The materials we use include the following glass types:

Soda-lime glass (AR, I860, PH360 etc.)
Borosilicate glass (DURANⓒ, PYREXⓒ, SIMAXⓒ etc.)
Neutral glass (FIOLAXⓒ and DUROBAXⓒ)
Aluminium silicate glass (Schott 8252/8253)
Quartz glass (naturally melted quartz glass and synthetically produced quartz glass, incl. F300)
Lead glass (lead content up to 28%)
Sealing glasses for various metals such as: kovar, molybdenum, steel, silver, platinum, palladium
Special glasses such as UV-glass or X-ray glass

*Dimensions
We manufacture capillaries with an outside diameter of 0,05-10 mm and offer various wall thicknesses and inner diameters.
With smaller diameters we are able to realize wall thicknesses as narrow as 10 μm (0,01 mm). In order to ensure a good handling, the smallest possible inner diameter ranges at 4- 5 μm at a wall thickness of 10-20 μm. Our standard manufacturing lengths are 1060 and 1500 mm.
Our flexible production enables us to produce lengths and blanks in the range of
1-3000 mm, according to customer requirements. Small capillaries with a diameter up to 0,25mm can even be processed to lengths greater than 3000 mm.
검색
전체선택
Thumbnail Catalog Description Packaging Specification
1406785 1406730 1406786 1406784 1406752 1406774 1406787 1406707 1406788 1406721 ... Quartz glass capillaries, ends cut • packaging unit (PU): 100 pieces • minimum order quantity: 100 pieces [그림참조] Quartz glass capillaries, ends cut
1403575 1403547 1403550 1403571 1403501 1403517 1405218 1405201 1405208 1404523 ... Borosilicate glass capillaries, ends cut (with filament) • packaging unit (PU): 100 pieces • minimum order quantity: 100 pieces [그림참조] Borosilicate glass capillaries, ends cut (with filament)
1403575 1403547 1403550 1403571 1403501 1403517 1405218 1405201 1405208 1404523 ... Borosilicate glass capillaries, ends cut (with filament) • packaging unit (PU): 100 pieces • minimum order quantity: 100 pieces [그림참조] Borosilicate glass capillaries, ends cut (with filament)
1408499 1406119 1405005 1409257 1408409 1408410 1409255 1405012 1406179 1409249 ... Borosilicate glass capillaries, ends cut (without filament) • packaging unit (PU): 100 pieces • minimum order quantity: 100 pieces [그림참조] Borosilicate glass capillaries, ends cut (without filament)
1405215 1405203 1405207 1403013 1403005 1403001 1404524 1404501 1404519 1403569 ... Borosilicate glass capillaries, ends cut (with filament) • packaging unit (PU): 100 pieces • minimum order quantity: 100 pieces [그림참조] Borosilicate glass capillaries, ends cut (with filament)
1405215 1405203 1405207 1403013 1403005 1403001 1404524 1404501 1404519 1403569 ... Borosilicate glass capillaries, ends cut (with filament) • packaging unit (PU): 100 pieces • minimum order quantity: 100 pieces [그림참조] Borosilicate glass capillaries, ends cut (with filament)
1405215 1405203 1405207 1403013 1403005 1403001 1404524 1404501 1404519 1403569 ... Borosilicate glass capillaries, ends cut (with filament) • packaging unit (PU): 100 pieces • minimum order quantity: 100 pieces [그림참조] Borosilicate glass capillaries, ends cut (with filament)
1403575 1403547 1403550 1403571 1403501 1403517 1405218 1405201 1405208 1404523 ... Borosilicate glass capillaries, ends cut (with filament) • packaging unit (PU): 100 pieces • minimum order quantity: 100 pieces [그림참조] Borosilicate glass capillaries, ends cut (with filament)
1403575 1403547 1403550 1403571 1403501 1403517 1405218 1405201 1405208 1404523 ... Borosilicate glass capillaries, ends cut (with filament) • packaging unit (PU): 100 pieces • minimum order quantity: 100 pieces [그림참조] Borosilicate glass capillaries, ends cut (with filament)
1403575 1403547 1403550 1403571 1403501 1403517 1405218 1405201 1405208 1404523 ... Borosilicate glass capillaries, ends cut (with filament) • packaging unit (PU): 100 pieces • minimum order quantity: 100 pieces [그림참조] Borosilicate glass capillaries, ends cut (with filament)
